Standard GB/T 19627-2005/ISO 13321:1996,
GB/T 29022-2012/ISO 22412:2008
Measure range 1nm-10000nm
Accuracy error ≤0.5% (CRM D50)
Repeatability error ≤0.5% (CRM D50)
Concentration range 0.1mg/ml - 100mg/ml
Light source 1 Semiconductor laser λ=532
or 639nm, power P=1-40mW (adjustable)
Light source 2 Blue laser λ=405nm, power P>2mW
Detector Photo-multiplier
Scattering angle 90°
Sample cuvette 10×10×40nm (1.4mL)
Test temperature 5-90°C
Temperature control accuracy ±0.1°C
Test speed <5 min
Outer dimension L60cm × W38cm × H23cm
G.W. 12Kg
Digital correlator model CR512
Auto-correlation channels 512
Baseline channel 4
Physical channels 10000
Unit delay time 100ns-10ms
Software SOP setting available, one-click automatic testing
