8 universal analog input channels:
Thermocouples, V, mV, mA, Pt100 and Pt1000
24-bit A/D conversion resolution.
8 digital I/Os (individually configured as input or output).
2 relay outputs (NO, NC and common).
RS485 interface (Modbus master or slave).
USB-device interface for configuring, monitoring and download.
Up to 32 configurable alarms.
Alarm actions: relays, digital outputs, emails, SNMP traps.
Up to 128 virtual channels for Mathematical functions: sum, subtraction, multiplication, division, logic (AND, OR, XOR), square root.
Keypad and color TFT QVGA display
Internal memory of up to 512,000 recordings.
Memory extension with SD or SDHC card.
Recording rate of 1000 logs/second (max).
Data download through software (USB device, RS485, Ethernet or USB drive).
