Principle Laser light scattering
Analysis Mie and Fraunhofer scattering
Detector Arrangement Log-spaced array, test angle from 0.015 degree to 145 degree
Red Light source Max.4.0MW Fiber, 639nm
Optical path Reverse Fourier(Folded optical path)
Laser Safety Class 1
Measuring Range Wet:0.01μm-3500 μm Dry: 0.1μm-3000μm
Dry dispersion Dry-turbulence dispersion patent technology, normal shock wave
shear technique
Feeding Speed Adjustable (Variable speed knob)
Operation Mode Full automatic / manual control, freely choose
Dispersion medium Compressed Air, pressure: 0 to 6 bar
Optical bench alignment system Full automatic, precision is up to 0.2um
Full Test Speed per time Wet: ＜2 Min Dry : <1min
Inverval time per test result :500ms
Outer dimension L87×W37×H33cm , L44*W35*H38cm
Environmental Requirement: Temperature: 5-35℃ Humidity：＜85%
Storage temperature -20°C to +50°C
Net Weight 32+15 KG
